25. Slot the connector through the recess as shown.
26. Bend over the 2nd ex foil as shown.
27. Now position the SLIDE MODULE ASSEMBLY over the B-
COVER ASSEMBLY.
28. Close this connector rst.
29. Move the SLIDE MODULE ASSEMBLY down and close the 2nd
connector.
30. Now close the slider slowly and align it to the B-COVER
ASSEMBLY.

Nokia E65 Specifications

General

Display diagonal	2.2 \
Display resolution	240 x 320 pixels
Display number of colors	16.78 million colors
Internal memory	50 MB
Rear camera type	Single camera
Multimedia Messaging Service (MMS)	Multimedia Messaging Service (MMS) is a standard way to send messages that include multimedia content to and from a mobile phone over a cellular network
Ringer type	Polyphonic
Talk time (2G)	6 h
Battery capacity	1000 mAh
Standby time (2G)	260 h
Form factor	Slider
Product color	Silver
2G standards	GPRS
Bluetooth version	2.0+EDR

Weight and Dimensions

Depth	49 mm
Width	105 mm
Height	15.5 mm
Weight	115 g
