7. Remove the CMT KEYMAT.
8. Lift up the LCD AM.
9. Carefully open the ex connector of the display with the
SS-93.
10. Ease out the glued in EARPIECE with the SS-93.
11. Discard it, do not use this part again when reassemble.
12. Unscrew these 2 Torx Plus size 4 screws.
