22
CONFIDENTIAL
Copyright © 2007 NOKIA. All rights reserved.
E90 RA-6
Page (51) ISSUE 1
Service Manual Level 1&2
13. Lever out the CAMERA BUTTON…
14. …and the PUSH TO TALK BUTTON.
15. Open the assembly and lift the QWERTY COVER.
16. It is possible to remove the QWERTY KEYMAT without
unlocking the QWERTY COVER.
17. Carefully release the hidden clips of the QWERTY COVER,
located on the right side…
18. …on the middle near the LOGO PLATE…
