DISASSEMBLY INSTRUCTION9.
1. Needed tools: a Torx Plus size 6 screwdriver, metal
tweezers, a DC plug, the SS-93 opening tool, a dental pick and
the SRT-6.
2. Cover the window with a protective lm.
3. Unlock and open the SLIDE COVER ASSEMBLY.
4. Cover the CAMERA WINDOW with a protective lm.
5. Place the SS-93 between the KEYMAT and the edge of the
A-COVER and unlock the button clip rst.
6. Hold the SS-93 in the shown position and unlock the side clip
with SRT-6 by pressing it between the A-COVER and the B-COVER.
