43. Remove the IHF SPEAKER 2 remember to remove whole IHF
GASKET 2 residues.
44. Remove the MICROPHONE with the dental pick.
45. Use the DC plug to release the DC-JACK.
46. The DC-JACK drops out easily when turning the B-COVER.
47. The disassembly procedure is now nished.
