Nokia N8–00

Nokia N8-
00
RM-596
Service Manual Level 1&2
30 Confidential | Copyright © 2010 Nokia | All rights reserved Version 3.0
43) Close the HDMI HATCH and check that the TOP
COVER edges are attached properly.
44) Place the BATTERY PULL-OUT TAPE to the BATTERY
as shown. Press it down slightly to activate the
adhesive.
45) Insert the BATTERY as shown. 46) Place the shown end of the BATTERY LID and then
lower down the other end. Note that the BATTERY
PULL-OUT TAPE is left under the BATTERY LID.
47) Remove the protective film of the BOTTOM DECO
ASSY.
48) And attach it to the BOTTOM COVER.
