Nokia N91 Service Manual

Training and Vendor Development
CMO Operations & Logistics
Multimedia Creation & Support CONFIDENTIAL
27.Apr.2006
34
Service Manual N91 RM-43 / RM-158
Copyright © 2006 NOKIA Corporation. All rights reserved.
Approved 3.0
MGR
Page
(34)
GONOGO TEST19.
After the optical check, a GoNoGo test has to be carried out if the unit has been unscrewed to guarantee the functionality
of the phone.
Please refer to the actual information on NOKIA Online. When using delivered tester support les, take care of the
right setup according to the tester type and product type.
Please refer to “Recommended Service Equipment” on NOKIA Online.
Mobile Phone Tester
A battery tester lets you test the capacity of NOKIA batteries.
Please refer to the actual information on NOKIA Online.
http://www.astratec.co.uk/
http://www.cadex.com/
BATTERY TEST20.

Nokia N91 Specifications

General

Rear camera type	Single camera
Rear camera resolution	1600 x 1200 pixels
2G standards	EDGE, GPRS
Ringer type	Polyphonic
Panel type	LCD
Display resolution	176 x 208 pixels
Display number of colors	262144 colors
Internal memory	8192 MB
Multimedia Messaging Service (MMS)	Multimedia Messaging Service (MMS) is a standard way to send messages that include multimedia content to and from a mobile phone over a cellular network
Platform	Symbian
Bundled software	S60 software on Symbian OS
Operating system installed	Symbian OS
Product color	Black
Talk time (2G)	4 h
Standby time (2G)	190 h

Weight and Dimensions

Depth	22 mm
Width	55.2 mm
Height	113.1 mm
Weight	164 g
