Nokia N91 Service Manual

Training and Vendor Development
CMO Operations & Logistics
Multimedia Creation & Support CONFIDENTIAL
27.Apr.2006
9
Service Manual N91 RM-43 / RM-158
Copyright © 2006 NOKIA Corporation. All rights reserved.
Approved 3.0
MGR
Page
(34)
FLS-4S incl. ACF-8, Driver and User Guide
Dongle and flash device incorporated into one package, developed
specifically for POS use.
ACF-8
Universal Power Supply is used to power FLS-4S.
Travel Charger AC-4
Small and lightweight charger for fast charging of your phone battery.
Internal Battery BL-5c
Inserted under the back cover, this Li-Ion 970 mAh battery provides
power in a lightweight package.
Headset HS-28
Comfortable earphones combined with excellent audio quality provide
a pleasurable listening experience. Control your music and calls re-
motely, and use it together with compatible headphones of your own
choice. Available in Nokia N91 sales package.
SS-15X
Camera removal tool. One side is for disassembly, the other side for
assembly.
DKE-2
USB Cable
SERVICE TOOLS7.

Nokia N91 Specifications

General

Rear camera type	Single camera
Rear camera resolution	1600 x 1200 pixels
2G standards	EDGE, GPRS
Ringer type	Polyphonic
Panel type	LCD
Display resolution	176 x 208 pixels
Display number of colors	262144 colors
Internal memory	8192 MB
Multimedia Messaging Service (MMS)	Multimedia Messaging Service (MMS) is a standard way to send messages that include multimedia content to and from a mobile phone over a cellular network
Platform	Symbian
Bundled software	S60 software on Symbian OS
Operating system installed	Symbian OS
Product color	Black
Talk time (2G)	4 h
Standby time (2G)	190 h

Weight and Dimensions

Depth	22 mm
Width	55.2 mm
Height	113.1 mm
Weight	164 g
