Nokia N93 Service Manual

Training and Vendor Development
CMO Operations & Logistics
Multimedia Creation & Support CONFIDENTIAL
05.Nov.2007
20
Service Manual N93 RM-55 / RM-153 Copyright © 2006 NOKIA Corporation. All rights reserved.
Approved 7.0
MGR
Page (50)
19. Carefully place the Flip Soft Keymat. The snaps are very
delicate and can break easily.
20. Remove the protection lm from the Main Display. Slot the
ex foil through the Flip B-Cover.
21. Fit the Flip A-Cover Assembly, beginning from the bottom
side.
22. Click all snaps into their places.
23. Close the assembly. Insert both screws.
24. Set the correct torque.

Nokia N93 Specifications

General

Zoom capability	3x
Front camera type	Single camera
Rear camera resolution	2048 x 1536 pixels
Video capture resolution (max)	640 x 480 pixels
2G standards	EDGE, GPRS
Ringer type	Polyphonic
Panel type	TFT
Display diagonal	2.4 \
Display resolution	240 x 320 pixels
Display number of colors	262144 colors
Internal memory	50 MB
Compatible memory cards	miniSD
Multimedia Messaging Service (MMS)	Multimedia Messaging Service (MMS) is a standard way to send messages that include multimedia content to and from a mobile phone over a cellular network
Bundled software	Adobe Premiere Elements 2.0
Talk time (2G)	5.1 h
Battery capacity	1100 mAh
Standby time (2G)	240 h
Product color	Black

Weight and Dimensions

Depth	28.2 mm
Width	55.5 mm
Height	118.2 mm
Weight	180 g
