Service Manual N93 RM-55 / RM-153 Copyright © 2006 NOKIA Corporation. All rights reserved.
Approved 7.0
MGR
Page (50)
7. Remove the Keymat.
8. Open the SIM Flap and remove it as shown.
9. Remove the six torx plus size 6 screws in the order shown.
10. Carefully pry open the snaps of the Grip A-Cover with the SS-
93.
11. Separate the Grip B-Cover.
12. Push out the SD Bung Painted.
