13. Ease out the Antenna Assy with the SS-93 carefully and
remove it. The parts can be separate.
14. Hold down the Antenna Cover while lifting the Grip B-Cover.
15. Carefully release the metal latches of the SDSIM Support
Frame with the dental pic on both sides.
16. Lift up the SDSIM PWB Module.
17. Disconnect the Flex foil connector.
18. Bend out the metal latch as shown.
