Nokia N97 Service Manual

Nokia N97 RM-505/RM-506/RM-507
Service Manual Level 1&2
2
Confidential
 Copyright © 2010 NOKIA  All rights reserved
Version 4.0
Table of contents
1. Change history .............................................................................................................................................................................. 3
2. Copyright ......................................................................................................................................................................................... 4
3. Warnings and cautions .............................................................................................................................................................. 5
3.1 Warning s ............................................................................................................................................................................... 5
3.2 Cautions ................................................................................................................................................................................. 5
4. ESD protection ............................................................................................................................................................................... 6
5. Care and maintenance ............................................................................................................................................................... 7
6. Battery information .................................................................................................................................................................... 8
7. Exploded view ............................................................................................................................................................................... 9
8. Service devices ............................................................................................................................................................................ 10
9. SW-update .................................................................................................................................................................................... 11
10. Disassembly instruction ..................................................................................................................................................... 12
11. Assembly hints ....................................................................................................................................................................... 19
12. Solder components .............................................................................................................................................................. 20


Nokia N97 Specifications

General

Panel type	TFT
Display diagonal	3.5 \
Display resolution	360 x 640 pixels
Display number of colors	16.78 million colors
Ringer type	Polyphonic
Internal memory	32768 MB
Front camera type	Single camera
Rear camera resolution	2584 x 1938 pixels
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	1
Multimedia Messaging Service (MMS)	Multimedia Messaging Service (MMS) is a standard way to send messages that include multimedia content to and from a mobile phone over a cellular network
Form factor	Slider
Product color	Black
Talk time (2G)	6.5 h
Battery capacity	1500 mAh
Standby time (2G)	430 h
Personal info management (PIM)	Alarm clock, Calculator, Calendar, To-do list
2G standards	EDGE, GPRS
Data network	3G
Bluetooth version	2.0+EDR

Weight and Dimensions

Depth	15.9 mm
Width	55.3 mm
Height	117.2 mm
Weight	150 g
