Nokia RH-99 - Module Jig (MJ-130) Service Concept

Item Description Type
6 Power supply, included in FPS-8 sales package AFC-8
7 RS-232 (D9 – D9) cable, included in FPS-8 sales package AXS-4
8 Printer cable, included in FPS-8 sales package
9 Software protection key PKD-1
10 Service SW (PHOENIX)
Module jig (MJ-130) service concept
Figure 7 Module jig service concept
Item Description Type
1 Module jig MJ-130
2 RF test cable XCF-4
RH-99; RH-100; RH-105; RH-106
Service Tools
