Nokia RM-801 Service Manual

RM-801; RM-819(Nokia Lumia 800)
General Information
Issue 1 COMPANY CONFIDENTIAL Page 1-9
Copyright © 2011 Nokia. All rights reserved.
 Transceiver general specifications
Unit
Dimension(mm)
Weight(g)
Volume(cc)
Transceiver with BV-5JW 1450mAh
Li-Ion battery pack
116.5 x 61.2 x 12.1 mm 142 76
 RM-801 Main RF characteristics for GSM850/900/1800/1900, WCDMA VIII/II/I phones
QTR8200 System Module
Parameter
Unit
Number of RF channels(GSM)
GSM850:124, GSM900:174, DCS1800:374, PCS:299
Channel Spacing
200kHZ
Number of RF channels(WCDMA)
WCDMA2100:277, WCDMA1900:277, WCDMA900:152
Channel Spacing
200kHZ
 RM-819 Main RF characteristics for GSM850/900/1800/1900, WCDMA V/II/I phones
QTR8200 System Module
Parameter
Unit
Number of RF channels(GSM)
GSM850:124, GSM900:174, DCS1800:374, PCS:299
Channel Spacing
200kHZ
Number of RF channels(WCDMA)
WCDMA2100:277, WCDMA1900:277, WCDMA850:124
Channel Spacing
200kHZ
 Battery endurance
Battery
Talk time
Standby time
Music
Playback
Video Playback
H.264 720p 30fps
BV-5JW 1450mAh
Li-Ion battery
13h (GSM)
9.5h (WCDMA)
265h (GSM)
335h (WCDMA)
55h
7h
Note: Variation in operation times will occur depending on network parameters, phone setting and
usage.

Nokia RM-801 Specifications

General

Model	Nokia RM-801
Category	Handhelds
Camera (Front)	No
Camera	Yes
Expandable Memory	microSD, up to 32 GB
Battery Type	Li-Ion
Display Type	TFT
FCC ID	RM-801
Network	GSM
Bluetooth	Yes
USB	microUSB v2.0
