RM-801; RM-819(Nokia Lumia 800)
BB Troubleshooting and Manual Tuning Guide
Issue 1 COMPANY CONFIDENTIAL Page 3-35
Copyright © 2011 Nokia. All rights reserved.
Battery troubleshooting
TP09 (VBAT)
TP10 (GND)
Battery Connector J1200
