Nokia RM-970 - Page 25

Service Manual Level 1 and 2
Nokia 220
RM-969, RM-970, RM-971
Version 1.0
Product controls and interfaces
3
4
5
7
2
1
6
9
8
10
11
12
15
16
13
14
9 — Call key
8 — Right selection key
7 — Scroll key
6 — Left selection key
5 — Display
4 — Earpiece
3 — 3.5mm headset connector
2 — Flashlight
1 — Charger connector
10 — End/Power key
11 — Keypad
12 — Microphone
13 — Loudspeaker
14 — Camera
15 — BT antenna area
16 — Main antenna area
©2014 Nokia | Nokia Internal Use only | All Rights Reserved.
