Nokia X2-00 Service Manual

Nokia X2-
00
RM-618
Service Manual Level 1&2
3 Confidential • Copyright © 2010 NOKIA • All rights reserved Version 2.0
Change history
Status
Version No.
Date
Comments
Approved 1.0 10.5.2010 First approved version
Approved 2.0 21.6.2010 Exploded view updated
The purpose of this document is to help NOKIA service levels 1 and 2 workshop technicians to
carry out service to NOKIA products. This Service Manual is to be used only by authorized NOKIA
service suppliers, and the content of it is confidential. Please note that NOKIA provides also other
guidance documents (e.g. Service Bulletins) for service suppliers, follow these regularly and
comply with the given instructions.
While every endeavor has been made to ensure the accuracy of this document, some errors may
exist. If you find any errors or if you have further suggestions, please notify NOKIA using the
address below:
Nokia Care Academy
mailto:Service.Manuals@nokia.com
Please keep in mind also that this documentation is continuously being updated and modified,
so watch always out for the newest version.

Nokia X2-00 Specifications

General

Display Size	2.2 inches
Resolution	240 x 320 pixels
Camera	5 MP
Storage	48 MB
Expandable Storage	microSD, up to 16 GB
Dimensions	111 x 47 x 13.3 mm
Weight	81 g
Announced	2010, April
Network	GSM
GPRS	Class 32
EDGE	Class 32
SIM	Mini-SIM
Display Type	TFT, 256K colors
Call records	Yes
Video	Yes
Alert types	Vibration, MP3 ringtones
Loudspeaker	Yes, with stereo speakers
3.5mm jack	Yes
WLAN	No
Radio	Stereo FM radio with RDS
Messaging	SMS, MMS, Email, IM
Browser	WAP 2.0/xHTML, HTML
Games	Yes
Java	Yes, MIDP 2.1
Stand-by	Up to 624 h
Battery	Removable Li-Ion 860 mAh battery (BL-4C)
Operating System	Series 40
Released	2010
Phonebook	2000 entries
Bluetooth	v2.1, A2DP
USB	microUSB 2.0
Colors	Red, Silver
