Nokia X2-00 Service Manual

Nokia X2-
00
RM-618
Service Manual Level 1&2
6 Confidential • Copyright © 2010 NOKIA • All rights reserved Version 2.0
3. ESD PROTECTION
Nokia requires that service points have sufficient ESD protection (against
static
electricity) when servicing the phone.
Any product of which the covers are removed must be handled with ESD
protection. The SIM card can be replaced without ESD protection if the product
is otherwise ready for use.
To replace the covers ESD protection must be applied.
All electronic parts of the product are susceptible to ESD. Resistors, too, can be
damaged by static electricity discharge.
All ESD sensitive parts must be packed in metallized protective bags during
shipping and handling outside any ESD Protected Area (EPA).
Every repair action involving opening the product or handling the product
components must be done under ESD protection.
ESD protected spare part packages MUST NOT be opened/closed out of an ESD
Protected Area.
For more information and local requirements about ESD protection and ESD
Protected Area, contact your local Nokia After Market Services representative.

Nokia X2-00 Specifications

General

Display Size	2.2 inches
Resolution	240 x 320 pixels
Camera	5 MP
Storage	48 MB
Expandable Storage	microSD, up to 16 GB
Dimensions	111 x 47 x 13.3 mm
Weight	81 g
Announced	2010, April
Network	GSM
GPRS	Class 32
EDGE	Class 32
SIM	Mini-SIM
Display Type	TFT, 256K colors
Call records	Yes
Video	Yes
Alert types	Vibration, MP3 ringtones
Loudspeaker	Yes, with stereo speakers
3.5mm jack	Yes
WLAN	No
Radio	Stereo FM radio with RDS
Messaging	SMS, MMS, Email, IM
Browser	WAP 2.0/xHTML, HTML
Games	Yes
Java	Yes, MIDP 2.1
Stand-by	Up to 624 h
Battery	Removable Li-Ion 860 mAh battery (BL-4C)
Operating System	Series 40
Released	2010
Phonebook	2000 entries
Bluetooth	v2.1, A2DP
USB	microUSB 2.0
Colors	Red, Silver
