Nokia X2-00 Service Manual

Nokia X2-
00
RM-618
Service Manual Level 1&2
4 Confidential • Copyright © 2010 NOKIA • All rights reserved Version 2.0
1. COPYRIGHT
Copyright © 2010 Nokia. All rights reserved.
Reproduction, transfer, distribution or storage of part or all of the contents in this document in
any form without the prior written permission of Nokia is prohibited.
Nokia, Nokia Connecting People, and Nokia X and Y are trademarks or registered trademarks of
Nokia Corporation. Other product and company names mentioned herein may be trademarks or
tradenames of their respective owners.
Nokia operates a policy of continuous development. Nokia reserves the right to make changes
and improvements to any of the products described in this document without prior notice.
Under no circumstances shall Nokia be responsible for any loss of data or income or any special,
incidental, consequential or indirect damages howsoever caused.
The contents of this document are provided “as is”. Except as required by applicable law, no
warranties of any kind, either express or implied, including, but not limited to, the implied
warranties of merchantability and fitness for a particular purpose, are made in relation to the
accuracy, reliability or contents of this document. Nokia reserves the right to revise this
document or withdraw it at any time without prior notice.
The availability of particular products may vary by region.
IMPORTANT
This document is intended for use by qualified service personnel only.

Nokia X2-00 Specifications

General

Display Size	2.2 inches
Resolution	240 x 320 pixels
Camera	5 MP
Storage	48 MB
Expandable Storage	microSD, up to 16 GB
Dimensions	111 x 47 x 13.3 mm
Weight	81 g
Announced	2010, April
Network	GSM
GPRS	Class 32
EDGE	Class 32
SIM	Mini-SIM
Display Type	TFT, 256K colors
Call records	Yes
Video	Yes
Alert types	Vibration, MP3 ringtones
Loudspeaker	Yes, with stereo speakers
3.5mm jack	Yes
WLAN	No
Radio	Stereo FM radio with RDS
Messaging	SMS, MMS, Email, IM
Browser	WAP 2.0/xHTML, HTML
Games	Yes
Java	Yes, MIDP 2.1
Stand-by	Up to 624 h
Battery	Removable Li-Ion 860 mAh battery (BL-4C)
Operating System	Series 40
Released	2010
Phonebook	2000 entries
Bluetooth	v2.1, A2DP
USB	microUSB 2.0
Colors	Red, Silver
