Nokia X3-02 User Manual

11 Micro USB connector
12 Charger connector
13 Wrist strap hole
14 Volume keys
15 Keylock button
16 Camera lens
17 Nokia AV connector (3.5 mm)
Insert the SIM card and battery
Important: Do not use a mini-UICC SIM card, also known as a micro-SIM card, a
micro-SIM card with an adapter, or a SIM card that has a mini-UICC cutout (see figure)
in this device. A micro SIM card is smaller than the standard SIM card. This device does
not support the use of micro-SIM cards and use of incompatible SIM cards may damage
the card or the device, and may corrupt data stored on the card.
This device is intended for use with a BL-4S battery. Always use original Nokia batteries.
The SIM card and its contacts can be easily damaged by scratches or bending, so be
careful when handling, inserting, or removing the card.
1 Press the release buttons, and remove the cover. If the battery is inserted, lift the
battery out.
2 Insert a SIM card. Make sure the contact area of the card is facing down.
6Get started

Nokia X3-02 Specifications

General

Display Type	TFT resistive touchscreen, 256K colors
Resolution	240 x 320 pixels (~167 ppi pixel density)
Internal Storage	50MB
RAM	64MB
Main Camera	5 MP
Network Technology	GSM / HSPA
2G bands	GSM 850 / 900 / 1800 / 1900
3G bands	HSDPA 850 / 900 / 1900 / 2100
Speed	HSPA 10.2/2 Mbps
GPRS	Class 32
EDGE	Class 32
Status	Discontinued
SIM	Mini-SIM
Call Records	Yes
Video	Yes
Alert Types	Vibration, MP3 ringtones
Loudspeaker	Yes
3.5mm jack	Yes
Bluetooth	2.1, A2DP, EDR
Radio	Stereo FM radio, RDS
USB	microUSB 2.0
Messaging	SMS, MMS, Email, IM
Browser	WAP 2.0/xHTML, HTML
Java	Yes, MIDP 2.1
Talk time	Up to 5 h 20 min (2G) / Up to 3 h 30 min (3G)
Display Size	2.4 inches
Battery Capacity	Li-Ion 860 mAh (BL-4S)
Dimensions	106.2 x 48.4 x 9.6 mm
Weight	77.4 g
Announced	2010, September
Card Slot	microSD, up to 16 GB
Phonebook	2000 entries
WLAN	Wi-Fi 802.11 b/g
Games	Yes
Battery	Li-Ion 860 mAh (BL-4S)
Stand-by	Up to 408 h
Colors	Dark Metal, Lilac
