Nokia X3 Service Manual

Nokia X3
RM-540
Service Manual Level 1&2
4 Confidential | Copyright © 2009 Nokia | All rights reserved Version 1.0
2. COPYRIGHT
Copyright © 2009 Nokia. All rights reserved.
Reproduction, transfer, distribution or storage of part or all of the contents in this document in
any form without the prior written permission of Nokia is prohibited.
Nokia, Nokia Connecting People, and Nokia X and Y are trademarks or registered trademarks of
Nokia Corporation. Other product and company names mentioned herein may be trademarks or
tradenames of their respective owners.
Nokia operates a policy of continuous development. Nokia reserves the right to make changes
and improvements to any of the products described in this document without prior notice.
Under no circumstances shall Nokia be responsible for any loss of data or income or any special,
incidental, consequential or indirect damages howsoever caused.
The contents of this document are provided “as is”. Except as required by applicable law, no
warranties of any kind, either express or implied, including, but not limited to, the implied
warranties of merchantability and fitness for a particular purpose, are made in relation to the
accuracy, reliability or contents of this document. Nokia reserves the right to revise this
document or withdraw it at any time without prior notice.
The availability of particular products may vary by region.
IMPORTANT
This document is intended for use by qualified service personnel only.

Nokia X3 Specifications

General

Display type	TFT
Display diagonal	2.2 \
Display resolution	320 x 240 pixels
Display number of colors	262144 colors
Flash memory	2048 MB
Internal memory	53 MB
Flash card support	Yes
Maximum memory card size	16 GB
Flash type	LED
Sensor type	CMOS
Photo effects	Negative film, Neutral, Sepia
White balance	Auto, Daylight, Fluorescent, Incandescent
Image formats supported	JPG
Rear camera resolution (numeric)	3.2 MP
Data network	EDGE, GPRS, GSM
SIM card capability	Single SIM
Bundled software	MSN Messenger; Opera mini.
Playback formats	AMR, MIDI, MP3
USB 2.0 ports quantity	1
USB connector type	Micro-USB A
Headphone connectivity	3.5 mm
Multimedia Messaging Service (MMS)	Multimedia Messaging Service (MMS) is a standard way to send messages that include multimedia content to and from a mobile phone over a cellular network
Maximum frame rate	15 fps
Video compression formats	3GP, ASF, AVI, MP4
Video capture resolution (max)	176 x 144 pixels
Ringer type	Polyphonic
Audio formats supported	MP3
Polyphonic rings quantity	64
Battery type	BL-4CT
Talk time (2G)	7.5 h
Battery capacity	860 mAh
Standby time (2G)	380 h
Continuous audio playback time	26 h
Volume control	Rotary
Form factor	Slider
Personal info management (PIM)	Alarm clock, Calculator, Calendar, Converter, Countdown timer, Notes, Stopwatch, To-do list
Bluetooth version	2.1+EDR

Weight and Dimensions

Depth	14.1 mm
Width	49.3 mm
Height	96 mm
Weight	103 g
