Nolan N-Com B3 User Manual

B3
9
3.1. Installing the microphone
JET HELMETS OR FLIP-UP HELMETS
Fig. 9 Fig. 10
Fig. 11
Fig. 12
 Prepare the microphone by inserting the microphone
clamp, being careful to position it properly (Fig. 9)
Note: the flat part of the clamp must be facing upward
when the microphone is positioned as shown in
figure 11.
 Position the microphone in its support as shown in
figure 10, being careful that the fluorescent clamp is
facing toward the inside of the helmet.
 Insert screw in the microphone clamp; use the key to
screw in the microphone securing screw to the shell
frame.
FULL-FACE HELMETS
Fig. 13
Fig. 14
 Take the polystyrene cheek pad (left-hand side) and position the microphone in its housing, as
shown in fig. 13, making sure that the fluorescent band stays facing the inside of the helmet. (Fig.
14)
