Nolan N-Com R Series User Manual

9
3. INSTALLATION ON THE HELMET
Important: Prior to installing the N-Com system, it is recommended to write down the identification
code affixed to the product (see chapter 11.4).
The installation video can be found in the support section at www.n-com.it
3.1. Battery connection
• Open the e-box (Fig. 1).
• Connect the battery to the port (Fig. 2), taking care to insert it correctly. If necessary use the
provided flat head screwdriver to insert the battery connector fully into the port.
• Close the e-box (Fig. 3).
Fig. 1
Fig. 2
Fig. 3
3.2. Initial steps
• Before you install the B101 system on the helmet, make sure it turns on properly. Press the “n”
key for about 2 seconds, until the blue LED on the keypad lights up and you hear a beep in the
headset. Proceed with the installation.
• Remove the cheek padding (see helmet instructions).
• Remove the helmet edge gasket using the special tool (Fig. 4).
• Completely remove the gasket as shown in Fig. 4; by doing so you also remove the padding.
• Remove the “N-Com” plugs found at the back of the shell gasket and on the left side of the
helmet.
Fig. 4
Fig. 4B – ONLY FOR N87, N80-8, N100-5 HELMETS
