Page #10 background imageLoading...
Page #10 background image
5 TIME LEARNING
The gate is in closed position
1
Put in OFF the switch no. 10 of the DIP A The automation is in the CLOSED position.
2
* Push the button TIMES TherstmotorOPENS
... after the phase-deplacement, automatically... ... the second motor OPENS
3
Push the button TIMES (or START) (If the opening limit switches are
not available)
Therstmotorstops,waituntilthesecond
motor stops.
... If the limit switches are available, wait until both motors are
stopped.
Leave the PAUSE TIME you need.
4
Push the TIMES button The second motor CLOSES
... after the phase-deplacement time... ...therstmotorcloses.
5
Press the TIMES button (or START) (if the limit switches are not
available)
The second motor stops, wait until the
rst motor stops.
END OF LEARNING TIME.
... if the limit switches are available wait when both motors stop.
The second motor stop, wait until thee
rst
motor stops.
END OF LEARNING TIME
5.1 TIME LEARNING: NORMAL WAY
10
7
8
9
*AftertherstpushoftheTIMESbuttonyoucanusetheterminalboardno.17
or the remote control as START as well.
The control board START S4XL has two way to plan the working time.
NORMAL WAY: use this way when all doors are the same and the motors are the same.
ADVANCED SYSTEM: use this way when you want top lan the exactly slown down and / or the doors have different
functions ways.
TIMES
10
