Assembly
5. Attach assembly to mounting bracket
. Unhook the assembly from the mounting bracket.
. Hold the assembly by the canopy and raise up to
align the two holes in the canopy with the holes in
the mounting bracket.
. Tighten the loosened screws. Now re-secure the
screws and washers which were removed (see Fig. 9).
ASSEMBLY
6. Install the light kit
10
and install the glass shade onto the light kit
by turning the glass shade clockwise (see Fig. 10).
Toll Free: 1-866-827-4985 model no. 052-6966-2
