6.4 Standard DIP Switch Settings
The standard DIP switch settings on the main circuit board should be set as
follows:
Mobile Multiple Animal
Switch # Position Description
1 Open
DO NOT CHANGE
2 Closed DO NOT CHANGE
3 Closed DO NOT CHANGE
4 Open DO NOT CHANGE
5 Open DO NOT CHANGE
6 Closed DO NOT CHANGE
7 a) Closed
b) Open
a) Kilograms (kgs)
b) Pounds (lbs)
8 Closed DO NOT CHANGE
OnBoard
The standard DIPswitch settings on the main circuit board should be set as
follows:
Switch # Position Description
1 Open
DO NOT CHANGE
2 Closed DO NOT CHANGE
3 Closed System ID number
4 Open DO NOT CHANGE
5 Open DO NOT CHANGE
6 Closed DO NOT CHANGE
7 c) Closed
d) Open
c) Kilograms (KGS)
d) Pounds (LBS)
8 Closed DO NOT CHANGE
