Note: Some sprayer types do not support a wiring test or they may support a different style of test. If
there are no messages displayed in this step, simply continue as prompted by the panel.
8.1.5 Sensor Detect
Position all boom sections such that the nozzles are 35 inches (90 cm) from the ground.
Press to continue.
Note: If it is not possible to get all the booms set to exactly 35 inches (90 cm), the sensor height can be
adjusted after the install is finished. Refer to Section 8.3.1 for more details.
Hold the
button to begin the sensor detect sequence. The button must be held for
the duration of the procedure. If is released, simply press and hold again to continue
the procedure.
The control panel will automatically move the booms to detect and assign the sensors to
the correct locations.
Release the button to continue.
Switch Release
Proceed?
Hold Auto Until
“Done”
Height
35 inch Booms at Level
Left Dn Press
Rght Up Press
Rght Dn Press
Main Up Press
Main Dn Press
To Next Page
