Automatic Dead Zone Calibration:
 Follow Section 8.1.1 (level booms, working RPM, etc.) before proceeding.
 Ensure the UC4.5 control panel is in manual mode, at the run screen.
 Navigate to the "More?" menu prompt in the SETUP ( ) menu. Press to confirm.
 Navigate to the boom section to be set up, for example "Left?" to adjust the left up or the
left down settings. Press the button to confirm.
 Press the button to access the next menu prompt. Choose the dead zone up or down
setting (Figure 10).
 Press and hold the button.
 When the "Done" message is displayed, release the button to view the new setting.
Manual Dead Zone Calibration:
 Follow Section 8.1.1 (level booms, working RPM, etc.) before proceeding.
 Ensure the UC4.5 control panel is in manual mode, at the run screen.
 Navigate to the "More?" menu prompt in the SETUP ( ) menu. Press to confirm.
 Navigate to the boom section to be setup, for example, "Left?" to adjust the left up and/or
the left down settings. Press the button to confirm.
 Press the button to access the next menu prompt. Choose the dead zone up or down
setting (Figure 10).
 Press and hold the button.
 The valve will turn on at the indicated setting for exactly one second. The screen will show
the actual change in height.
 The change in height reading is live as long as the button is held. Wait until the height
reading has settled to a stable value and record this reading.
 Average three readings. The acceptable average change in height should be from 0.5 to 1.5
inches (13 to 38 mm). Ideal would be 1 inch exactly (25 mm).
 If the average is less, increase the DZ setting with the
button. If the average is more,
decrease the DZ setting with the button.
 Repeat the manual dead zone test until the average falls into the acceptable range.
