8.3.4 Turning Booms Off or On
The UC4.5 automatic height control can be turned off for each individual boom section. In
automatic mode, boom sections that are turned off will not automatically adjust and are
indicated with a "D" in the run screen, as shown in Figure 12.
Turning off the left channel, for example, will disable the left section’s automatic control;
however, manual height readings from this section will still be available. The sprayer’s wing
booms will still be controlled automatically.
Left Channel is turned off ("D" = Disabled)
Figure 12: Turning a Boom Off (for Left Channel)
Ensure the UC4.5 control panel is in manual mode and at the run screen.
Navigate to the "More?" menu prompt in the SETUP (
) menu. Press to confirm.
Navigate to the boom section to be turned off or on, for example, "Left?". Press the
button to confirm.
At the "Left On" menu prompt use the buttons to change the status.
Press and hold the or button for two seconds to return to the run screen.
D 45 A
