5.2. HeightSensorTest
1. Inspectfoampadsandsensors.Installcleandryfoampadsifnecessary.
2. Performthistestoverlevelbaresoilorgravel.ThesystemmustbeinmanualandSoilMode™.
3. Leveltheboomsandadjustthemainlifttothebottomofthe
stroke.
4. Navigate to the height readings screen (Run Screen‐> Settings‐> Next‐> Next‐> Diagnostics‐>
Sensors).
5. Checkthereadingsofalltheheightsensorswhileraisingthecentersection.
6. A continuous and accurate heightreading from 10 inches (25 cm) to80 inches (200 cm)
 should be
seen.
7. Repeatsteps2to6inCropMode™.
 
Serial Numbe
r
