Electronic connection

Connecting leads

Use the adaptor bundle connected to the device’s multiconnector

and the relevant inputs and outputs on the other side. Ensure

that the connections are properly made and the insulation of both

connected and disconnected lead is good!

Connector/Object Connect to

1 Pink lead Parking brake (-)

2 Violet lead Rear-view camera (B+)

3 ISO connector See previous description

4 Yellow cable Video output
