5 Red cable Rear line output (R - right)
6 White cable Rear line output (L - left)
7 Red cable Front line output (R - right)
8 White cable Front line output (L - left)
9 Red cable Audio input (R - right)
10 White cable Audio input (L - left)
11 Yellow cable Video input
12 Brown cable Video camera
13 Blue cable Subwoofer
14 White lead SWC Line 1
15 Green lead SWC Line 2
16 Black lead SWC Line Ground (earth)
17 Black cable Radio antenna
18 DAB connector See previous description
19 Black cable External Mic Jack (Black)
CONTROL LEAD
Parking brake: Connect this lead to the vehicle's hand brake
system
Rear-view camera: Connect to the reverse indicator light. Voltage
should be supplied to this lead when reverse is put into gear.
ATTENTION
To prevent accidents, it is forbidden to watch video while
driving. This unit is ready for this feature the installation is
made correctly. To watch video, park in a safe place and
set the parking brake.
