1210 SERIES PARTS LIST - PAGE 11
ICE MAKER AND RELATED COMPONENTS - 1210 SERIES - NON-DISPENSER MODELS
NO. PART # DESCRIPTION
1210AC
MODELS
1210
MODELS
1211
MODELS
1 61656822 COVER-FRONT/ICE MAKER X X X
2 621266 ICE MAKER (61656522 WITH AREA AT FILL TUBE ENTRY REMOVED) X X X
3 61690822 CLAMP-TUBING/IM X X X
4 621429 WAT ER TUBE/HEAT ER ASSY/FOR ICE M AKER ( M ODELS WIT HOUT DISPENSER) X X X
625879 WAT ER TUBE/HEAT ER ASSY/FOR ICE M AKER ( M ODELS WIT H DISPENSER) X X X
5 61541422 BUSHING-SNAP X X X
6 620039 FITTING-WATER TUBE/IM/4.17" X X X
7 618407 WIRING HARNESS-IM X X X
8 620890 BRACKET-IM MOUNTING X X X
9 618253 WATER VALVE-SINGLE PORT X X X
624516 WAT ER V AL V E- DUAL PORT /DISPENSER X X X
10 618169 SPACER-WATER V AL V E/NYL ON ( 2 PER ASSEM BL Y) X X X
11 61679622 GARDEN HOSE ADAPTER-STRAIGHT/IM X X X
12 622991 NUT-COMPRESSION/WATER VALVE FITTING/IM/PLASTIC X X X
622846 NUT- BRASS/GARDEN HOSE ADAPT ER X X X
625880 NUT- COM PRESSION 5/16"/DISPENSER M ODELS X X X
13 61656922 SHUT OFF ARM/IM X X X
14 618803 BIN-ICE XXX
15 618847 SHELF-WIRE/FREEZER X X X
NS 620240 THERMOSTAT-IM HEATER ASSY X X X
NS = NOT SHOWN
ART00912B
15
14
13
12
11
10
9
8
7
7
6
5
5
4
4
2
3
1
