1210 SERIES PARTS LIST - PAGE 7
CABINET ASSEMBLY - FRONT VIEW - 1210 SERIES
.
.
NO. PART # DESCRIPTION
1210AC
MODELS
1210
MODELS
1211
MODELS
1 623528 KIT-INSTALLATION ("U" TRIM PIECES/SCREWS/CAPS) X X X
NS 618170 HOL E PLUG- FOR TOP TRIM PIECE/BL ACK X X X
2 623899 HINGE PIN-UPPER/BLACK X X X
3 628946 HINGE-OUT SIDE/UPPER RH/L OWER L H X X X
4 61550722 HINGE PIN-LOWER X X X
5 624363 HINGE-INSIDE/UPPER RH/LOWER L H X X X
6 624 364 HINGE- INSIDE/UPPER LH/LOWER RH X X X
7 627955 COVER-HINGE/1210 SERIES X X X
8 623254 TRIM PIECE-SIDE/WITH "U" TOP/BOTTOM TRIM PIECE X X X
9 622033 RETAINER-SHELF X X X
10 628945 HINGE-OUTSIDE/UPPER LH/LOWER/RH X X X
11 631360 GUIDE BLOCK ASSY-BOTTOM/BLACK (SERIAL # 10414601 & ABOV
E
XXX
631366 KIT-FLAPPER ASSY/GUIDE BLOCKS (SERIAL# 10414600 & BELOW) X X X
12 618785 FINS XXX
13 618774 DRIP TRAY-INSIDE/CABINET X X X
NS 622392 DRAIN HOSE ASSY- 1200 SERIES X X X
14 620689 PROBE-CONTACT/LARGE X X X
15 623918 SWITCH-DOOR LIGHT/1200 SERIES X X X
16 620871 LAMP THERMISTER WIRE ASSY X X X
17 629113 CONTROL ASSY-OPTICAL/GE/1210 SERIES X X
629817 CONTROL ASSY-OPTICAL/AC/1210 SERIES X
18 621827 COVER-LAMP BRACKET X X X
NS 61629722 LAMP BRACKET ASSY X X X
NS 61628922 LAMP-GE #214-2/DC LIGHT BULB X X X
19 631359 GUIDE BLOCK ASSY-TOP/BLACK (SERIAL # 10414601 & ABOVE) X X X
631366 KIT-FLAPPER ASSY/GUIDE BLOCKS (SERIAL# 10414600 & BELOW) X X X
20 628473 STRIKE PLATE-BLACK X X X
21 624366 FRONT BOX- DUM M Y BOX ( NON- DISPENSER M ODELS ONL Y) X X X
NS 628460 PLATE- FOR DUM M Y BOX ( NON- DISPENSER M ODEL S ONLY) X X X
628454 CONTROL PANEL (DISPENSER MODELS ONLY) X X X
22 618847 SHELF-WIRE/FREEZER/1200 SERIES X X X
23 618849 SHELF-WIRE/SHORT/1200 SERIES X X X
24 618848 SHELF-WIRE/LONG/1200 SERIES X X X
25 618757 CRISPER COVER-GLASS SHELF X X X
26 628688 BIN-BOTTLE/CRISPER X X X
27 628694 DIVIDER-BOTTLE CRISPER X X X
28 618840 SUPPORT WALL-FOR CRISPER BIN X X X
29 625210 STRIP-FREEZER-BLACK X X X
NS 61630422 ICE CUBE TRAY- PLAST IC ( NON- ICE M AKER M ODEL S ONL Y) X X X
NS = NOT SHOWN
