Norcold 442 - Page 12

400 SERIES PARTS LIST - PAGE 12
BOTTOM PAN/CONTROL ASSEMBLY - 400 SERIES
Continued on Page 13
NO. PART # DESCRIPTION
442
443
452
453
462
463
482
483
1 61705222 BURNER ASSY-5 SLOT X X X X
2 61454322 ORIFICE-LP#11/.0115 (USE 618866) X
61452122 ORIFICE-LP#14 (USE 618866) X X
61452222 ORIFICE-LP#16 (USE 618865) X X
3 61475122 ORIFICE GASKET X X X X
4 61448622 FITTING-FOR BURNER TUBE (USE 61692622 & 61692722) X X X X
61692722 FITTING-GAS TUBE CONNECTION X X X X
61692622 SLEEVE-BALL/.25"/TUBE COMPRESSION RING/BRASS X X X X
5 61638422 BURNER TUBE X
61648622 BURNER TUBE X
61641622 BURNER TUBE X
61643522 BURNER TUBE X
6 61546822 CONNECTOR-MALE X X X X
7 61436322 THERMOCOUPLE X X X X
8 61638522 INLET TUBE XXXX
9 61436622 BUSHING-OPEN/CLOSED/3/8" X X X
10 61639122 COVER PLATE-BURNER TUBE X X X X
11 61746122 RELIGHTER-WITH GROUND WIRE X X X X
12 61692322 MANUAL SHUT OFF VALVE ASSY X X X X
13 61638822 TERMINAL BLOCK-EG2 EG2 EG2 EG2 EG2
61638922 TERMINAL BLOCK-EG3 EG3 EG3 EG3 EG3
NS 61647122 COVER-TERMINAL BLOCK (NOT SHOWN) X X X X
14 61646222 CORD-AC POWER X X X X
15 61395922 BUSHING-RELIEF X X X X
16 61638722 FUSE HOLDER XXXX
NS 61446022 FUSE-GLASS/15 AMP/EG3 (NOT SHOWN) EG3 EG3
NS 61440522 FUSE-GLASS/20 AMP (NOT SHOWN) EG3 EG3
NS 61654622 FUSE-GLASS/3 AMP/32V OR LESS (NOT SHOWN) X X X X
NS 61611622 FUSE-GLASS/5 AMP/110 VOLT (NOT SHOWN) X X X X
17 61639010 COVER PLATE-RELIGHTER X X X X
18 61639222 BRACKET-MANUAL SHUT OFF VALVE X X X X
19 61772022 BOTTOM PAN-SUPPORT ASSY X X X X
