Norcold 442 - Page 13

400 SERIES PARTS LIST - PAGE 13
BOTTOM PAN/CONTROL ASSEMBLY - 400 SERIES Continued from Page 12
NO. PART # DESCRIPTION
442
443
452
453
462
463
482
483
20 624274 KIT-COMBINATION CONTROL WITH FITTINGS (CONTACT NORCOLD RECALL) X X X X
21 61631222 BRACKET-CONTROL MOUNTING/FRONT X X X X
22 61694822 SWITCH-EG3/3 POSITION EG3 EG3 EG3 EG3
23 61644022 CONTROL PANEL-BOTTOM/EG2 EG2 EG2 EG2 EG2
61631122 CONTROL PANEL-BOTTOM/EG3 EG3 EG3 EG3 EG3
24 61641822 KNOB-SELECTOR X X X X
25 61642322 KNOB-THERMOSTAT X X X X
26 61651722 GASKET-CONTROL COVER (NOT SHOWN) X X X X
27 61649722 SWITCH-INDICATOR X X X X
28 61609022 INDICATOR LIGHT-FLAME X X X X
NS 61607822 ELECTRODE ASSY-SPARK/SENSE 1/8" (NOT SHOWN) X X X X
NS 61692222 ELECTRODE-SPARK/SENSE/SINGLE ELECTRODE/0.25" (NOT SHOWN) X X X X
NS 61644122 WIRING HARNESS-EG2 (NOT SHOWN) EG2 EG3
NS 61638622 WIRING HARNESS-EG3 (NOT SHOWN) EG3 EG3
NS 61645822 WIRING HARNESS-EG2 (NOT SHOWN) EG2 EG2
NS 61645922 WIRING HARNESS-EG3 (NOT SHOWN)(USE 61645822) EG3 EG3
