9100 SERIES PARTS LIST - PAGE 2
DOOR - UPPER (FREEZER) - 9100 SERIES
NO. PART # DESCRIPTION 916 918
1 618128 PANEL RETAINER-UPPER DOOR X X
2 618511 HINGE-DOOR SIDE/TOP RH/BTM LH/BLACK X X
3 618144 HINGE BUSHING-DOOR HINGE/BLACK X X
4 618205 DOOR LINER ASSY-UPPER/GRAY DOOR GASKET X X
620076 DOOR LINER ASSY-UPPER/WHITE DOOR GASKET (USE 619627) X X
5 618160 CAP-HINGE PLUG/BLACK XX
6 619569 BOLT-CAP SHOULDER/TORX HEAD X X
7 618235 DOOR HANDLE ASSY-UPPER DOOR/RH SWING/BLACK (USE 619574) X X
8 618119 STORAGE LATCH-DOOR/BLACK (USE 619648) X X
9 618510 HINGE-DOOR SIDE/TOP LH/BTM RH/BLACK X X
10 618618 RAIL-UPPER DOOR XX
