Installation Options
Install a Decorative Door Panel
The decorative door panel must be 2.0 mm (0.08 inches) or less in
thickness.
1. Remove the door from the refrigerator by removing
the four screws that attach the door hinge to the bottom
of the refrigerator (Art02326).
2. Remove the panel retainer by removing the three
screws that attach the panel retainer (Art02327).
3. Gently pull the door panel out of the door (Art01895).
4. Push a new door panel into the door slot.
Do not over-tighten the screws
and bolts.
5. Put the panel retainer in the original location and at-
tach with three screws.
6. Put the door in the original location and tighten the
four screws.
!
12
Art02326
screws
door hinge
Art02327
Panel retainer
Screw
Art01895
Door panel
Reverse The Door Swing
1. Remove the door from the refrigerator by removing
the four screws that attach the door hinge to the bot-
tom of the refrigerator.
2. Open the door and pull it off of the top hinge pin.
3. Remove the three screws that attach the upper
hinge (Art02328).
4. Remove the three screws that attach the latch to the
refrigerator.
5. Remove the hole plugs.
6. Attach the upper hinge and the door latch to the op-
posite sides of the refrigerator. Put the hole plugs into
the empty holes.
Art02328
Door latch
Upper hinge
Plugs
