When using either a converter or a battery charger, make sure that they are connected In parallel
between the battery and the refrigerator. Do not use a converter or battery charger to supply the DC
power directly to the refrigerator because these two devices do not supply filtered DC power (Art01521).
14
Art01518A
Electrical equipment
INCORRECT CORRECT
Battery
Battery
Refrigerator Refrigerator
Twist lead wires
Art01521B
Refrigerator Refrigerator
Refrigerator
Refrigerator
INCORRECT
INCORRECT
CORRECT CORRECT
Battery charger
Battery charger
Transistorized
DC power supply
Transistorized
DC power supply
1. twist the lead wires to reduce the radio interference and induction of a high voltage
surge from the outside (Art01518).
2. Connect the DC power supply.
To Next Page
