Norcold N109X Series User Manual

N109X ModelsRefrigerator Service Manual
5
Storage volume
N109X -------------------------------------------------------------------------------------------------------------------------------- 9.5 ft
3
.
Rough opening dimensions (H x W x D)
N109X -------------------------------------------------------------------------------------------------------59
7
/8 in. x 23
1
/2 in. x 24 in.
Decorative panels dimensions
Thickness ----------------------------------------------------------------------------------------------------------------------------
3
/16 in.
Freezer door (H x W) ----------------------------------------------------------------------------------------- 14
17
/32 in. x 21
19
/32 in.
Fresh food compartment door -------------------------------------------------------------------------------- 38
5
/8 in. x 21
19
/32 in.
Controls
Type ------------------------------------------------------------------------------------- Electronic with built-in diagnostic function
ON/OFF/MODE/TEMP SET switches -----------------------------------------------------------------Raised pushbutton style
Temperature settings ---------------------------------------------------------------------------------------------- 1=cold, 9=coldest
Temperature sensor -----------------------------------------------------------------------------Thermistor, n mounted (10
th
n)
Off-level operating limits
Side-to-side--------------------------------------------------------------------------------------------------------3 degrees maximum
Front-to-back ------------------------------------------------------------------------------------------------------6 degrees maximum
DC power
Controls operating voltage ----------------------------------------------------------------------------------------- 10.5 to 15.4 Vdc
DC fuse (F1 in power board) ------------------------------------------------------------5 A (tan color), automotive blade type
DC amp draws (at nominal 12 VDC)
Automatic ignition ------------------------------------------------------------------------------------------------------------------ 0.50 A
Divider heater ----------------------------------------------------------------------------------------------------------------------- 0.25 A
Fresh food compartment lamp ------------------------------------------------------------------------------------------------- 0.46 A
Gas valve ---------------------------------------------------------------------------------------------------------------------------0.146 A
Fan ------------------------------------------------------------------------------------------------------------------------------------ 0.36 A
AC power
AC heater operating voltage requirements ---------------------------------------------------------------------- 108 to 132 VAC
Fuse ac heater circuit (F3 in power board) -------------------------------------- 5 A,
1
/4 in. x 1
1
/4 in. AGC type fast acting
AC heater rating ----------------------------------------------------------------- 300 W/2.5 A @ 120 VAC (resistance of 48 Ω)
LP gas (propane)
Operating pressure ----------------------------------------------------------------------------------------------- 10.5 to 11.5 in. w.c.
Heat input ---------------------------------------------------------------------------------------------------- 1500 Btu/h @ 11 in. w.c.
Orice -----------------------------------------------------------------------------------------------------------------------------------LP16
Gas ignition ----------------------------------------------------------------------------------- Automatic with ame sensing circuit
Electrode tip-to-burner air gap ------------------------------------------------------------------------------------------
1
/8 to
3
/16 in.
N109X Models
SPECIFICATIONS

Norcold N109X Series Specifications
