15
•
Remove and clean the drawer.
•
After cleaning, place the drawer back in reverse order.
Removing drawer (N2160)
To remove the drawer (N2160):
•
Pull the drawer until the stop and push it a little bit back.
•
Then push the guide locks backwards, as illustrated.
•
Pull the drawer further to the front and lift the wheels over the curves.
•
Remove and clean the drawer.
•
After cleaning, pull out the guides until they snap into place.
•
Place the drawer back in reverse order.
13. Emptying the drip tray (N2090)
During use, water will collect on the back wall of the refrigerator. If the external drainage option
is not used, the condensation will collect in the drip tray. To empty the drip tray:
•
Pull the drip tray up until it releases from the mounting hook in the back.
•
Remove the drip tray from the refrigerator and empty it.
