Owner’s Manual 11
Wiring Diagram and Pictorial
The parts of the wiring diagram are (See Art01775):
The parts of the wiring pictorial are (Art01776):
AC heater .....................................................................................A
Thermister ....................................................................................B
Gas valve..................................................................................... C
Igniter........................................................................................... D
Temperature switch (optional) ......................................................E
Fan (optional) ...............................................................................F
DC heater (optinal) ...................................................................... G
Chassis ground............................................................................ H
DC board (optional) ......................................................................I
Switched 12 VDC .........................................................................1
Fused continuous 12 VDC............................................................2
Communications ...........................................................................3
Display ground..............................................................................4
Auxiliary ground (optional) ............................................................5
Auxiliary +12 VDC (optional) ........................................................6
Gas valve +12 VDC ......................................................................7
5 A Fuse DC ...............................................................................F1
8A Fuse AC.................................................................................F2
30 A Fuse DC .............................................................................F3
Replacement Parts
You may purchase replacement parts through your local RV
dealer or an authorized Norcold Service Center.
8. Examine the gas supply line for leaks.
9. Connect the DC wiring to the refrigerator:
- Install the DC fuse or connect the DC wiring to the battery or
the converter.
- Connect the DC wires from the refrigerator.
10. Connect the AC power cord to the receptacle.
