Owner’s Manual 11
Wiring Pictorial
Wiring Diagram
The parts in the wiring pictorial are(See Art01577):
1 ............................................................120 VAC Power cord
2 ....................................................................... -12 VDC com
3 .............................................................................. +12 VDC
4 ........................................................................ Power board
5 ..............................................................Gas solenoid valve
6 ................................................ Thermister / light assembly
8 ...................................................................... Divider heater
9 .............................................................................AC heater
10 .................................................................... Fan (optional)
11.........................................................Thermostat (optional)
12 .................................................................... Display board
17 ................................................................. Spark electrode
18 .........................................................................5 Amp fuse
The parts in the wiring diagram are (See Art01578):
1 ........................................................... 120 VAC Connection
2 ...................................................................... -12 VDC Com
3 .............................................................................. +12 VDC
4 ........................................................................ Power board
5 ..............................................................Gas solenoid valve
6 ........................................................................... Thermister
7 ..........................................................................Interior light
8 ...................................................................... Divider heater
9 .............................................................................AC heater
10 .................................................................... Fan (optional)
11.........................................................Thermostat (optional)
12 .................................................................... Display board
13 .................................................................. Selector switch
14 ...........................................................Temperature switch
15 ................................................................. Microprocessor
16 .................................................................................... LED
To Next Page
