N62/N82 SERIES PARTS LIST - PAGE 5
CABINET AREA (FRONT VIEW) - N62/N82 SERIES
NO. PART # DESCRIPTION N62 SERIES N82 SERIES
1 622319 TRIM PIECE ASSY-TOP/WITH INSERTS/BLACK X X
2 618170 HOLE PLUG-BLACK (2 PER CABINET) X X
3
623771 HINGE-CABINET/3 POINT/TOP RH/BTM LH/PANEL/BLACK/SDL X X
619335 HINGE-CABINET/3 POINT/TOP RH/BTM LH/PANEL/BLACK/WDL X X
624785 HINGE-CABINET/3 POINT/TOP RH/BTM LH/WRAP/BLACK/SDL X
4
622295 TRIM PIECE FOAM TAPE ASSY-CABINET/SIDE/6’ (2 PER CABINET) X
622296 TRIM PIECE FOAM TAPE ASSY-CABINET/SIDE/8’ (2 PER CABINET) X
5 620250 SHELF-WIRE/FREEZER X X
6
628974
CONTROL ASSY-OPTICAL/BLACK (SERIAL# : N621/N821/N822=9126825 & ABOVE - N623/N823=8970881 &
ABOVE) X X
633292
KIT-CONTROLS ADAPTER (SERIAL#: N621/N821/N822=9126824 & BELOW - N623/N823=8970880 & BELOW) X X
7 619282 FRONT BOX-BLACK X X
8 623250 DRIP TRAY-INSIDE X X
9 620272 SHELF-WIRE/CUT OUT X X
10 620273 SHELF-WIRE/FULL 2 3
11 618158 CRISPER COVER-GLASS SHELF X X
12 618571 CRISPER-WHITE/FULL X X
13
618145 HINGE PIN-UPPER HINGE/BLACK/WDL/SDL X X
623899 HINGE PIN-UPPER/LOWER/BLACK/WDL/SDL X X
61550722 HINGE PIN-BOTTOM/WDL/SDL X X
14 619671 HINGE BUSHING-DOOR/WARM GRAY (4 PER REFRIGERATOR) X X
15
623772 HINGE-CABINET/3 POINT/TOP LH/BTM RH/PANEL/BLACK/SDL X X
619336 HINGE-CABINET/3 POINT/TOP LH/BTM RH/PANEL/BLACK/WDL X X
624786 HINGE-CABINET/3 POINT/TOP LH/BTM RH/WRAP/BLACK/SDL X
16 619301 COVER-HINGE HOLES/WHITE/3 POINT X X
17 622323 TRIM PIECE FOAM TAPE ASSY-CABINET/BOTTOM X X
18
618181 RETAINER-SHELF (SERIAL # 926963 AND BEFORE) X X
622033 RETAINER-SHELF (SERIAL # 926964 AND AFTER) X X
19
619561 HOLE PLUG-DIVIDER/WHITE (PRODUCED 03/12/98 TO 07/20/98) X X
620282 HOLE PLUG-DIVIDER/WHITE (PRODUCED 07/21/98 TO 02/14/99) X X
20
618167 STRIKE PLATE X X
622325 KIT-INSTALLATION (TRIM PIECES/SCREWS/PLUGS)(NOT SHOWN) X X
NOTE: IF THE CONTROL ASSY-OPTICAL HAS BEEN REPLACED WITH A KIT-CONTROL ADAPTOR, THE POWER BOARD MUST BE REPLACED WITH A
NEW KIT-CONTROL ADAPTER.
