N62/N82 SERIES PARTS LIST - PAGE 7
CONTROLS (REAR VIEW) - MODELS N62/N82 SERIES
NOTE: FOR MODELS MADE WITH A SEPARATE MANUAL SHUT OFF VALVE (SERIAL # 656979 & BELOW).
NO. PART # DESCRIPTION N62 SERIES N82 SERIES
1 618186 BASE-POWER BOARD X X
2 632168001 KIT-POWER BOARD
SEE NOTE SEE NOTE
3 618185 COVER-POWER SUPPLY X X
4 621448 WIRE-WHITE/9”/GAS VALVE (2 PER ASSEMBLY) X X
5 61694022 BRACKET-MOUNTING/GAS VALVE X X
6 61594422 PRESSURE TAP X X
61445322 PLUG-1/8”/FOR PRESSURE TAP X X
7 621334 KIT-GAS VALVE/BRACKET/WIRES X X
8 61546822 CONNECTOR-MALE X X
9 61694622 UNION TUBE X X
10 621444 MANUAL SHUT OFF VALVE ASSY X X
11 618252 BURNER TUBE X X
12 621957 KIT-BURNER/ORIFICE ADAPTER ASSY X X
13 61554422 CORD-AC POWER/BLACK X X
14 61712637 COVER ASSY-BURNER BOX X X
15 61695322 BASE-BURNER BOX X X
NOTE: IF THE CONTROL ASSY-OPTICAL HAS BEEN REPLACED WITH A KIT-CONTROL ADAPTOR, THE POWER BOARD MUST BE REPLACED WITH A
NEW KIT-CONTROL ADAPTER.
