N62/N82 SERIES PARTS LIST - PAGE 6
CABINET AREA (REAR VIEW) - N62/N82 SERIES
NO. PART # DESCRIPTION N62 SERIES N82 SERIES
1 61686823 FINS X X
2 61695022 CAP-HEAT DEFLECTOR X X
3
621702
HEATER-AC (COOLING UNIT SERIAL# 11231023 & BELOW) X
HEATER-AC (COOLING UNIT SERIAL# 11232007 & BELOW) X
630811
HEATER-AC/BACKER (COOLING UNIT SERIAL# 11231024 & ABOVE) X
HEATER-AC/BACKER (COOLING UNIT SERIAL# 11232008 & ABOVE) X
4 61695322 BASE-BURNER BOX X X
5 61712637 COVER ASSY-BURNER BOX X X
6 622546 DRIP CUP-REAR X X
7 622390 DRAIN HOSE ASSY X
8 622391 DRAIN HOSE ASSY X
9 61505122 HOSE CLAMP (NOT USED WITH DRAIN HOSE ASSY 622390/622391) X X
10 632307 NSC SYSTEM PACK-COOLING UNIT (BACKER HEATER) X
11 632314 NSC SYSTEM PACK-COOLING UNIT (BACKER HEATER) X
NS 2M0802 THERMAL SWITCH/BRACKET ASSY (SEE NOTE) X X
NS 618111 BAFFLE DIFFUSER/WIRE ASSY-COOLING UNIT (NOT SHOWN) X X
NS 61695022 CAP-HEAT DEFLECTOR (NOT SHOWN) X X
NOTE: FOR COOLING UNITS WITH A THERMAL SWITCH.
