12
16. Identify the Right Pedal (21). Using your fingers,
turn the Right Pedal about halfway into the Right
Crank Arm (23). Then, use an adjustable wrench
to FIRMLY TIGHTEN the Right Pedal.
Repeat this step with the Left Pedal (not
shown). IMPORTANT: You must turn the Left
Pedal COUNTERCLOCKWISE to attach it.
To adjust the pedal straps (E), see HOW TO
ADJUST THE PEDAL STRAPS on page 14.
16
23
10
75
88
81
15
15. Slide the Backrest Back (81) onto the Seat
Handlebar (10).
Attach the Backrest Back (81) with four
M6 x 30mm Screws (75) and four M6
Washers (88); start all the Screws, and then
tighten them.
21
E
To Next Page
