9. Remove the Seat Knob (26) from the Seat
Bracket (30) inside the Seat Carriage (24).
Next, hold the Seat Carriage (24) on the Seat
Post (6). Insert the Seat Knob (26) upward into
the Seat Post, and tighten the Seat Knob into the
Seat Bracket (30) inside the Seat Carriage.
9
26
24
6
28
27
6
10. Loosen the Seat Post Knob (27) and pull it out-
ward. Next, insert the Seat Post (6) into the Seat
Post Sleeve (28), and then release the Seat Post
Knob. Move the Seat Post upward or down-
ward slightly to make sure that the Seat Post
Knob is engaged in one of the adjustment
holes in the Seat Post. Then, tighten the Seat
Post Knob.
30
