13
17. After the exercise bike is assembled, inspect it to make sure that it is assembled correctly and that it
functions properly. Make sure that all parts are properly tightened before you use the exercise bike.
Extra parts may be included. Place a mat beneath the exercise bike to protect the floor.
16. IMPORTANT: Always plug the Power Adapter
(67) into the exercise bike before you plug it
into an outlet.
Plug the Power Adapter (67) into the Power
Receptacle (2) on the exercise bike.
Note: To plug the Power Adapter (67) into an
outlet, see HOW TO PLUG IN THE POWER
ADAPTER on page 14.
16
67
2
15. Set the two Hand Weights (87) on the Right and
Left Armrests (59, 69) and on the Hand Weight
Rest (49).
IMPORTANT: Make sure not to hit the
Console (9) with the Hand Weights (87) when
you pick up and set down the Hand Weights.
15
87
69
49
87
59
9
To Next Page
