13
11. Start two #8 x 1/2" Screws (2) into the Crossbar
(87), and then tighten them; do not overtighten
the Screws.
11
2
87
10. Attach the console assembly (G) to the
Handrails (81, 82) with four 1/4" x 1/2" Screws
(21) that you removed in step 7 and four 1/4"
Star Washers (37); start all four Screws, and
then tighten them. Be careful not to pinch the
wires (I).
Insert any excess wire (I) into the top of the Right
Upright (84).
10
21
37
G
37
21
82
81
I
84
